Fire Fighting Pump (Electric-Diesel-Jockey) EDJ Set (Redurbished)

🔥 Fire Fighting Pump Sets – Diesel Engine Driven

High-Performance Fire Protection Solutions

City Fire & Safety Services (Pvt) Ltd offers reliable and cost-effective Diesel Engine Driven Fire Pump Systems, designed to ensure uninterrupted water supply during fire emergencies. Each system is a complete package that combines a main diesel pump, an electric backup pump and a Grundfos jockey pump, supported by a new control panel, batteries, and essential accessories for seamless operation.

Our pump sets are available in different capacities (250, 350, 500 GPM and 750 GPM at 7–8 Bar) to meet the specific needs of small, medium, and large-scale facilities. All systems are professionally refurbished, tested for quality, and supplied with a 3-Month Warranty, offering excellent performance at competitive prices.

🔧 250 GPM Fire Pump System

Duty: 250 GPM @ 7.0 bar (≈71.4 m head)

Main Diesel Pump

• Horizontal end-suction or split-case fire pump

• Outlet: 3″

• Rated: 250 GPM @ 7 bar

• Driver: 30 HP (≈22 kW), 4-cylinder diesel engine, battery start, SAE flywheel, engine-mounted alternator for battery charging

Electric Backup Pump

• End-suction centrifugal, KSB (or equivalent)

• Size: 4″ × 3″

• Motor: 30 HP (≈22 kW)

Jockey Pump

• Grundfos (or equivalent)

• Size: 2″ × 2″

• Motor: ~3 HP

• Set pressure: 7.5–8.0 bar (slightly above working pressure)

Control Panel & Accessories (New)

• Automatic/manual control, pressure switches/transducers

• Phase failure & overload protection

• Start/stop indicators & remote start/stop

• Battery charger (for diesel start batteries)

• Pump run timers, test/exercise circuits

• Alarm circuits: low oil, low coolant, failure to start, overspeed, high temp

• NRV, gate valves, gauges, Y-strainers, flanges, baseplate & coupling guards

Condition / Warranty: Refurbished (min 3 months)
Indicative Price (PKR): 3,000,000

🔧 350 GPM Fire Pump System

Duty: 350 GPM @ 7.0 bar (≈71.4 m head)

Main Diesel Pump

• Horizontal end-suction or split-case fire pump

• Outlet: 3″

• Rated: 350 GPM @ 7 bar

• Driver: 40 HP (≈30 kW), 4-cylinder diesel engine, battery start

Electric Backup Pump

• KSB (or equivalent), 4″ × 3″

• Motor: 40 HP (≈30 kW)

Jockey Pump

• Grundfos (or equivalent), 2″ × 2″

• Motor: ~3 HP

• Set pressure: slightly above working pressure (≈7–8.0 bar)

Control Panel & Accessories (New): Same as 250 GPM

Condition / Warranty: Refurbished (min 3 months)
Indicative Price (PKR): 3,600,000

🔧 500 GPM Fire Pump System

Duty: 500 GPM @ 8.0 bar (≈81.6 m head)

Main Diesel Pump

• Horizontal end-suction or split-case fire pump

• Outlet: 4″

• Rated: 500 GPM @ 8 bar

• Driver: 75 HP (≈56 kW), turbocharged/suitable industrial diesel engine, battery start

Electric Backup Pump

• KSB (or equivalent), 5″ × 4″

• Motor: 75 HP (≈56 kW)

Jockey Pump

• Grundfos (or equivalent), 2″ × 2″

• Motor: ~5 HP

• Set pressure: slightly above working pressure (≈8.5–9.0 bar)

Control Panel & Accessories (New): Same as 250 GPM

Condition / Warranty: Refurbished (min 3 months)
Indicative Price (PKR): 4,200,000

🔧 750 GPM Fire Pump System

Duty: 750 GPM @ 7.0 bar (≈71.4 m head)

Main Diesel Pump

• Horizontal end-suction or split-case fire pump

• Outlet: 4″

• Rated: 750 GPM @ 7 bar

• Driver: 100 HP (≈75 kW), 6-cylinder diesel engine, battery start

Electric Backup Pump

• KSB (or equivalent), 5″ × 4″

• Motor: 100 HP (≈75 kW)

Jockey Pump

• Grundfos (or equivalent), 2″ × 2″

• Motor: ~10 HP

• Set pressure: 10–11 bar (higher than main cut-in pressure)

Control Panel & Accessories (New): Same as 250 GPM

Condition / Warranty: Refurbished (max 6 months)
Indicative Price (PKR): 5,500,000

✔ Diesel Pump + Electric Backup Pump + Grundfos Jockey Pump
✔ New Control Panel & Accessories
✔ Battery-operated auto ignition
✔ 3-Month Warranty on all units
✔ Nationwide delivery across Pakistan

✅ Commercial Complexes – Shopping malls, office towers, residential buildings, hotels, and apartment blocks
✅ Industrial Facilities – Factories, manufacturing plants, refineries, oil & gas terminals, and power plants
✅ Warehouses & Logistics Hubs – Storage depots, distribution centers, and bonded warehouses
✅ Healthcare & Education – Hospitals, laboratories, universities, and schools
✅ High-Risk Sites – Airports, ports, chemical storage areas, and critical infrastructure

With robust diesel engines, powerful electric backup pumps, and automatic jockey pumps, City Fire’s pump sets deliver constant water pressure and maximum reliability, even in the most challenging environments.

⚡ City Fire & Safety Services (Pvt) Ltd – Your Trusted Partner in Fire Protection
