🔥 Instant Fire Extinguisher – 1 Kg & 1.5 Kg
Manual Throw Fire Extinguishing Device (ABC Type)
Product Description
The Instant Fire Extinguisher is a throw-type fire suppression ball-device charged with ABC Dry Chemical Powder, primarily based on mono-ammonium phosphate. It is designed for rapid control of incipient-stage fires by interrupting the chemical chain reaction of combustion and forming a smothering layer over burning surfaces.
The device is engineered for instant activation and discharge without the need for hoses, nozzles, pressure gauges, or technical training—making it ideal for emergency use by untrained personnel.
Extinguishing Mechanism (Technical)
-
Chemical chain reaction interruption by free-radical inhibition
-
Surface smothering effect preventing oxygen contact
-
Thermal insulation layer on Class A fuels, reducing re-ignition
-
Rapid flame knockdown on flammable liquids and gases
The ABC powder is non-conductive, making it safe for energized electrical equipment.
Fire Classification & Suitability
| Fire Class | Description |
|---|---|
| Class A | Solid combustibles: wood, paper, cloth, plastics |
| Class B | Flammable liquid: Petrol, diesel, oils (open surface fires only) |
| Class C | Flammable gases & energized electrical equipment |
| Electrical Fires | Live panels, wiring, machinery |
| Mechanical Equipment | Motors, generators, compressors |
Method of Operation
-
Pierce or remove the sealed safety paper cover.
-
Remove the activation lanyard from the device.
-
Pull the lanyard sharply with force to initiate activation.
-
Immediately throw the extinguisher toward the base of the fire.
âš The unit must be thrown within 3 seconds of lanyard activation for effective discharge.
Upon impact, the shell ruptures and disperses ABC dry chemical powder in all directions.
Performance Characteristics
-
Instant, pressure-free activation
-
Fast flame knockdown at incipient stage
-
360° powder dispersion on impact
-
Electrically non-conductive agent
-
No aiming or hose handling required
-
Suitable for use by untrained occupants
Safety Precautions & Limitations
âš Caution
-
❌ Do NOT throw into flammable liquid fires inside containers (tanks, drums, enclosed vessels)
-
For early-stage fires only; not suitable for deep-seated or fully developed fires
-
Avoid inhalation of powder; evacuate area after discharge
-
Not reusable after activation
Technical Specifications
| Parameter | Specification |
|---|---|
| Extinguisher Type | Throw-Type Instant Fire Extinguisher |
| Extinguishing Agent | ABC Dry Chemical Powder (Mono-Ammonium Phosphate) |
| Net Weight | 1.0 Kg and 1.5 Kg |
| Activation Method | Manual lanyard pull + impact rupture |
| Discharge | Instant upon impact |
| Electrical Safety | Non-conductive, safe for live equipment |
| Operating Principle | Chemical inhibition & smothering |
| Warrantee | 05 Years |
| Country of Origin | China |
| Price | 1 Kg Instant Fire Extinguisher: Rs. 1,800/-
1.5 Kg Instant Fire Extinguisher: Rs. 2,200/- |
Typical Applications
-
-
Residential buildings & apartments
-
Electrical rooms & panels
-
Workshops & small industrial units
-
Warehouses & storage facilities
-
Vehicles & machinery rooms
-
Emergency response kits
-
