⚙️ 24V DC Electrical Solenoid Actuator with Manual Strike Function
For FM-200 / HFC-227ea Fire Suppression Systems
Product Overview
This Solenoid Actuator Valve is specially engineered for use in FM-200 and HFC-227ea fire suppression systems. It offers precise, reliable activation of discharge valves, with a latching actuation design that includes a manual reset and strike function for added safety and redundancy. Built to perform under high pressure, this actuator ensures optimal reliability in critical fire protection scenarios.
Technical Specifications
| Feature | Details |
|---|---|
| System Application | FM-200 / HFC-227ea Fire Suppression |
| Actuation Type | Latching (Manual Reset Required) |
| Power Type | Solenoid |
| Working Voltage | 24V DC |
| Current Draw | 0.25 A |
| Max Monitoring Current | 25 mA |
| Pin Travel | 4.4 mm (0.171 in) |
| Working Pressure | 4.2 MPa (42.3 bar) |
| Pressure Rating | High Pressure |
| Electrical Connection | 3-Pin Plug Connector |
| Connection Size | 1″ BSPP (Brass) |
| Actuation Pin Material | Stainless Steel |
| Body Material | Brass, Nickel Plated |
| Reset Requirement | Manual Reset |
| Country of Origin | China |
Key Features
🔒 Latching Mechanism with manual strike ensures secure actuation and added safety
⚡ Low Power Draw (0.25 A) for efficient and reliable system integration
🧩 Easy Electrical Integration via 3-pin plug connector
🛡️ High Durability with corrosion-resistant stainless steel and nickel-plated brass construction
✅ Manual Reset Option for system integrity during maintenance and emergencies
Applications
-
FM-200 / HFC-227ea fire suppression cylinder valves
-
Data centers, server rooms, and telecom facilities
-
Electrical control rooms
-
Industrial clean agent fire protection systems
